QuickSpecs
HP Z2 G9 Tower Workstation Desktop PC
System Technical Specifications
c08109687 — DA 17012 – Worldwide — Version 13 — November 1, 2022 Page 29
System board revision
level Allows management SW to read revision level of the system board.
Revision level is digitally encoded into the HW and cannot be modified.
Start-up Diagnostics
(Power-on Self-Test) Assesses system health at boot time with selectable levels of testing.
Auto Setup when new
hardware installed System automatically detects addition of new hardware.
Keyboard-less Operation The system can be booted without a keyboard.
Localized ROM Setup Common BIOS image supports System Configuration Utility (F10 Setup) menus in 15 languages with
local keyboard mappings.
Asset Tag The user or MIS to set a unique tag string in non-volatile memory.
Per-slot Control Allows I/O slot parameters (option ROM enable/disable, bus latency) to be configured individually.
Adaptive Cooling Control parameters are set according to detected hardware configuration for optimal acoustics.
Pre-boot Diagnostics (Pre-video) critical errors are reported via beeps and blinks on the power LED.
UEFI Specification
Revision
2.7
ACPI Advanced Configuration and Power Management Interface, Version 6.0
ATA (IDE) AT Attachment 6 with Packet Interface (ATA/ATAPI-6), Revision 3b
CD Boot "El Torito" Bootable CD-ROM Format Specification Version 1.0
EDD Enhanced Disk Drive Specification Version 1.1
BIOS Enhanced Disk Drive Specification Version 3.0(Not support)
EHCI Enhanced Host Controller Interface for Universal Serial Bus, Revision 1.0
PCI PCI Local Bus Specification, Revision 2.3
PCI Power Management Specification, Revision 1.1
PCI Firmware Specification, Revision 3.0, Draft .7
PCI Express PCI Express Base Specification, Revision 2.0
PCI Express Base Specification, Revision 3.0
PCI Express Base Specification, Revision 4.0
PCI Express Base Specification, Revision 5.0 Ready
PMM POST Memory Manager Specification, Version 1.01
SATA Serial ATA Specification, Revision 1.0a
Serial ATA 3 Gb/s: Serial ATA Specification, Revision 2.5
Serial ATA 6 Gb/s: Serial ATA Specification, Revision 3.0
SPD JEDEC JESD300-5
TPM Trusted Computing Group TPM Specification Version 2.0 (Infineon SLB 9670).
Common Criteria EAL4+ certified.
FIPS 140-2 Certification
TCG TPM Certified products list:
http://www.trustedcomputinggroup.org/certification/tpm-certified-products/
UHCI Universal Host Controller Interface Design Guide, Revision 1.1
USB Universal Serial Bus Revision 1.1 Specification
Universal Serial Bus Revision 2.0 Specification
Universal Serial Bus Revision 3.1 Specification
Universal Serial Bus Revision 3.2 Specification
SMBIOS System Management BIOS Reference Specification, Version 3.4
External BIOS simulator found at: http://csrsml.itcs.hp.com/
Social and Environmental Responsibility
Eco-Label Certifications
& Declarations This product has received or is in the process of being certified to the following approvals and may be
labeled with one or more of these marks:
