QuickSpecs

HP Z2 G9 Tower Workstation Desktop PC

Technical Specifications - Networking and Communications

c08109687

—

DA 17012

–

Worldwide

—

Version 13

—

November 1, 2022

Page 53

Integrated Intel® I219LM
PCIe GbE Controller
(Intel® vPro® with Intel

AMT 16.0

)

Connector

RJ-45

Cabling

Twisted pair up to 100m

Controller

Intel® I219LM GbE platform LAN connect networking controller

Memory

3 KB Tx and 3KB Rx FIFO packet buffer memory

Data Rates Supported

10/100/1000 Mbps

Compliance

802.1as/1588, 802.1p, 802.1Q, 802.3, 802.3ab, 802.3az, 802.3i, 802.3u,
802.3z

Bus Architecture

PCI Express and SMBus

Data Transfer Mode

PCIe-based interface for active state operation (S0 state) and SMBus for
host and management traffic (Sx low power state)

Power Requirement

Requires 3.3V (integrated regulators for core Vdc)

Boot ROM Support

Yes

Network Transfer Mode

Full-duplex; Half-duplex

Network Transfer Rate

10BASE-T (half-duplex) 10 Mbps
10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T (full-duplex) 2000 Mbps

Management Capabilities

vPro®, WOL, auto MDI crossover, PXE, Muti-port teaming, RSS, ACPI,

Advanced cable diagnostic, loopback modes,
AMT 16.0 support, Circuit Breaker, VLAN, Multicast Listener Discovery
(MLD)

Requires activation and a system with a corporate network connection, an Intel® AMT enabled

chipset, and network hardware and software. For notebooks, Intel AMT may be unavailable or limited
over a host OS-based VPN, when connecting wirelessly, on battery power, sleeping, hibernating, or
powered off. Results dependent upon hardware, setup, and configuration. For more information, visit:
https://www.intel.com/content/www/us/en/architecture-and-technology/intel-active-management-
technology.html

HP 1-Port 1GbE Flex IO
NIC
