QuickSpecs
HP Z2 G9 Tower Workstation Desktop PC
Technical Specifications - Networking and Communications
c08109687 — DA 17012 – Worldwide — Version 13 — November 1, 2022 Page 55
Data Rates Supported 100/1000 Mbps
Compliance IEEE 802.1p priority encoding/tagging (QoS, CoS)
IEEE 802.1q VLAN tagging
IEEE 802.3x flow control
Bus Architecture USB
Power Requirement Requires 3.3V (integrated regulators for core Vdc)
Boot ROM Support Yes
Network Transfer Mode Full-duplex; Half-duplex
Network Transfer Rate 100BASE-X (half-duplex) 100 Mbps
1000BASE-X (half-duplex) 1000 Mbps
1000BASE-X (full-duplex) 2000 Mbps
Operating Temperature 32° to 158° F (0°C to 70°C)
calvin 1.5 in x 1.7 in. x 0.75 in (3.84 cm x 4.3 cm x 1.9 cm)
Operating System Driver
Support Windows 11 64-Bit
Windows 10 64-bit
Linux®
Intel® I225-T1 1-Port
2.5GbE NIC Connector RJ-45
Cabling Cat5e (or better) up to 85m
Controller Intel® Ethernet I225 Controller
Network Transfer Rates
Supported 2.5GbE, 1GbE, 100MbE, 10MbE
Data Path Width PCIe Gen3.1x1
Power Requirement 1.9W (typical)
Operating Temperature 32° to 158° F (0°C to 70°C)
Dimensions (HxW) 2.7 in x 2.57 in. (68.7mm x 65.3mm)
Operating System Driver Windows 11 64-Bit
Windows 10 64-bit
Linux®
Kit Contents • Intel®️ I225 -T1 1-Port 2.5GbE NIC with standard height bracket attached
Low-profile bracket
• Product Literature
Intel® Wi-Fi 6E* AX211
802.11ax, BT 5.2, M.2
With Internal Antenna WLAN Standards 802.11abgn+acR2+axR2(Pre-Standard) MIMO 2x2
High performance, low power dual band Pre-Standard-802.11ax R2 2x2,
both with 160MHz channel support
– Wi-Fi 6E
Antenna 2x2 Dual-Band (internal)
Bluetooth Standards 5.2
Operating Temperature 32° to 176° F (0° to 80° C)
Interface M.2 CNVio2
Dimensions M.2 2230
Kit Contents Not Available
NOTE: The AX211 with internal antenna only support WIFI 6
*Wi-Fi 6E requires a Wi-Fi 6E router, sold separately, to function in the 6GHz band. Availability of public
wireless access points limited. Wi-Fi 6E is backwards compatible with prior 802.11 specs. And available
in countries where Wi-Fi 6E is supported.
