QuickSpecs
HP Z2 G9 Tower Workstation Desktop PC
Technical Specifications - Graphics
c08109687 — DA 17012 – Worldwide — Version 13 — November 1, 2022 Page 45
NVIDIA® T400 2GB
Graphics* Form Factor Single Slot, Low Profile (2.7” H x 6.1” L)
Graphics Controller Turing architecture
Max Power: 30 Watts
Cooling Solution: Active fan heatsink
Bus Type PCI Express 3.0 x16
Memory 2GB GDDR6 Memory
Memory Bandwidth: 80 GB/s
Memory Interface: 64 bit
Connectors 3x mDP (Mini DisplayPort ™ ) 1.4 Connectors
Max simultaneous
displays - 3x 3840 x 2160 @ 120Hz
- 3x 5120 x 2880 @ 60Hz
- supports Multi-Stream Transport (MST)
Shading Architecture DirectX 12 Shader Model 5.1
Supported Graphics APIs OpenGL 4.6
DirectX 12
Vulkan 1.2
API support includes:
CUDA, OpenCL 1.2
Available Graphics
Drivers Windows 10 64-bit
Windows 11 64-bit
Linux® 64-bit (selected Enterprise distributions)
HP qualified drivers may be preloaded or available from the HP support
Web site:
http://welcome.hp.com/country/us/en/support.html
*May go End of Life in late 2022
NVIDIA® T400 4GB
Graphics Form Factor Single Slot, Low Profile (2.7” H x 6.1” L)
Graphics Controller Turing architecture
Max Power: 30 Watts
Cooling Solution: Active fan heatsink
Bus Type PCI Express 3.0 x16
Memory 4GB GDDR6 Memory
Memory Bandwidth: 80 GB/s
Memory Interface: 64 bit
Connectors 3x mDP (Mini DisplayPort ™ ) 1.4 Connectors
Max simultaneous
displays
- 3x 3840 x 2160 @ 120Hz
- 3x 5120 x 2880 @ 60Hz
- supports Multi-Stream Transport (MST)
Shading Architecture DirectX 12 Shader Model 5.1
Supported Graphics APIs OpenGL 4.6
DirectX 12
Vulkan 1.2
API support includes:
CUDA, OpenCL 1.2
Available Graphics
Drivers Windows 10 64-bit
Windows 11 64-bit
