HP Z2 G9 Tower Workstation - Manual (Page 48)

QuickSpecs
HP Z2 G9 Tower Workstation Desktop PC
Technical Specifications - Graphics
c08109687 — DA 17012 – Worldwide — Version 13 — November 1, 2022 Page 48
Bus Type PCI Express 3.0 x16
Memory 8GB GDDR6 Memory
Memory Bandwidth: 160 GB/s
Memory Interface: 128 bit
Connectors 4x mDP (Mini DisplayPort ™ ) 1.4 Connectors
Max simultaneous
displays - 4x 3840 x 2160 @ 120Hz
- 4x 5120 x 2880 @ 60Hz
- 2x 7680 x 4320 @ 60Hz
- supports Multi-Stream Transport (MST)
Shading Architecture DirectX 12 Shader Model 5.1
Supported Graphics APIs OpenGL 4.6
DirectX 12
Vulkan 1.2
API support includes:
CUDA, OpenCL 1.2
Available Graphics
Drivers Windows 10 64-bit
Windows 11 64-bit
Linux® 64-bit (selected Enterprise distributions)
HP qualified drivers may be preloaded or available from the HP support
Web site:
http://welcome.hp.com/country/us/en/support.html
NVIDIA® RTX ™ A2000
12GB Graphics
Form Factor Low-Profile Double Slot ( 2.7” H x
6.1” L)
Graphics Controller Ampere architecture
Power: 70 Watts
Cooling: Active Fan Heatsink
Bus Type PCI Express 4.0 x16
Memory 12GB GDDR6 memory
Memory Bandwidth: 288 GB/s
Memory Interface: 192 bit
Support Error-correcting code (ECC)
Connectors 4x mDP (Mini DisplayPort ™ ) 1.4 Connectors
Max simultaneous
displays 4x 4096 x 2160 @ 120 Hz,
4x 5120 x 2880 @ 60 Hz
2x 7680 x 4320 @ 60 Hz
Shading Architecture Shader Model 6.5
Supported Graphics APIs OpenGL 4.6
DirectX 12
Vulkan 1.2
API support includes:
CUDA, OpenCL 1.2
Available Graphics
Drivers Windows 10 64-bit
Windows 11 64-bit
Linux® 64-bit (selected Enterprise distributions)
HP qualified drivers may be preloaded or available from the HP support
Web site:
http://welcome.hp.com/country/us/en/support.html
