Introduction
Easy to integrate, the CLSO-612 was designed for conference and classrooms with inputs at
lecterns, tables, and desks. Sources and displays can be up to 230 feet (70 meters) from the
switcher with HDBaseT inputs and outputs. Local HDMI and multifunction analog inputs work with
any source. Combined with great features such as: 4K up/down scaling, microphone ducking, and
audio control, this is the core component of your presentation AV system.
Package Contents
Features
• 1 x AT-UHD-CLSO-612
• 11 x Female Captive Screw Connector (6 pin: audio, 5 pin: IR, 3 pin: RS-232, 3 pin: MIC/Line)
• 1 x 24V/2.7A DC power supply adaptor (AT-PW24V2.7A)
• 1 x Pair of dual purpose wall/rack mounts
• 1 x IR Remote Control
• 1 x User manual
• Accepts HDMI and HDBaseT inputs from up to 230 feet away
• Multifunctional VGA ports for RGBHV, component, S-Video, and composite signals
• Microphone (dynamic, phantom, and line) input with ducking
• HDBaseT output mirrored to HDMI output
• Auto switching - automated switching to last connected source without using a control system
• Balanced audio inputs for embedding audio
• Balanced (+4 dbu) analog audio output for de-embedding audio to amplifiers or audio systems
• Upscaling and downscaling to ensure compatibility with any display up to 4K resolution
• Control via RS-232, IR, TCP/IP, WebGUI, and multi-language On-Screen Display
• Master and sub volume control
• Adjust treble and bass on audio output to ensure the best speaker performance
• PoCC to HDBaseT inputs and outputs (no power required with compatible devices)
• HDCP Compliant
• Supports 3D pass through
