HARDWARE INSTLLATION
SW1-SW8 for EDID/Audio
DIP Switch
Position
Video
Audio
Description
Pin-1
Pin-2
OFF
[©]
OFF
[©]
Up to 1080p
Surround
1
Default Mode
2
– Up to 1080p video & surround
sound audio output up to 7.1ch (DTS-HD & Dolby
TrueHD)
OFF
[©]
ON
[ª]
Up to 1080p
Stereo
Safe Mode
3
–
Enforce the system output at 1080p
video and stereo audio for basic compatibility
among HDTVs
ON
[ª]
OFF
[©]
Bypass
4
Bypass
4
EDID Learning Mode
5
– for learning EDID from
the display while playing any received HDMI
™
audio format
ON
[ª]
ON
[ª]
Bypass Stereo
EDID Learning & Stereo Mode
5
– for learning
EDID from the display while enforcing stereo output
if any HDTV cannot play surround sound normally
Note
1
If the HDTV shows video but without audio, please try to set audio mode to stereo.
2
Factory default setting of [SW1]-[SW8] is pin-1 at OFF [
©] & pin-2 at OFF [©] for 1080p video
and surround sound audio.
3
If you encounter any unsolved audio/video output problem during system installation, please
turn any [SW1]-[SW8] to pin-1 at OFF [
©] & pin-2 at ON [ª] for safe mode to enforce the system
output up to 1080p video and stereo audio for system check. However, the safe mode cannot
be initiated if your HDMI
™
source is set to enforce 1080p output. In this case, please
reconfigure your HDMI
™
source to all resolution output for troubleshooting.
4
Bypass means the matrix will maintain playing the original format of HDMI
™
signals in video
and perhaps audio. By setting at this mode, the users may encounter compatibility issue
among different kinds of HDMI
™
sources and displays. If you cannot get the audio and/or video
output normally at the system installation, please change the DIP switch setting to default
mode or even safe mode to verify the functionality of the device.
5
To learn the EDID of HDMI
™
display for respective HDMI
™
source devices, please see the [EDID
Learning] section in the next page for more detail information.
