12
HARDWARE INSTALLATION
PERFORMANCE GUIDE
HARDWARE INSTLLATION
AT-HD88M-S as master unit
1. Connect all sources to HDMI
™
Inputs on the 8x8 HDMI
™
over CAT5 matrix master AT-HD88M-
S
2. Connect each CHANNEL CONTROL output port on the AT-HD88M-S to respective CHANNEL
CONTROL
port on the remote receiver AT-HD88M-R
3. Connect each A/V SIGNAL output port on the AT-HD88M-S to respective A/V SIGNAL input
on the remote receiver AT-HD88M-R
4. Connect IR blaster to the IR MAIN jack of AT-HD88M-S and direct the IR blaster to the built-in
IR receiver of the sources
5. Connect the UL AC C13 power cord to the AT-HD88M-S
6. Power on all HDMI
™
sources
7. Power on the AT-HD88M-S
AT-HD88M-R as receiver unit
1. Connect each HDMI
™
output to HDMI
™
displays
2. Connect the A/V SIGNAL port on the AT-HD88M-R to the A/V SIGNAL port on the AT-HD88M-
S
3. Connect the CHANNEL CONTROL port on the AT-HD88M-R to the CHANNEL CONTROL
port on the AT-HD88M-S
4. Connect IR receiver and place the IR receiver at the appropriate position that can receive the
IR command signals sent from the users
5. Dial the 8-level rotary control switch to adjust the HDMI
™
signal level until the picture and
sound are clear
Performance rating
Type of CAT5/6 cable
Wiring
Shielding
CAT5
CAT5e
CAT6
Solid
Unshielded (UTP)
Shielded (STP)
Stranded
Unshielded (UTP)
Shielded (STP)
Termination
Please use EIA/TIA-568-B termination (T568B) at any time
