17
Display Side
Method A: Push button for switching input channels
Press the INPUT SELECT push button to switch the input source on the respective output port
connected to the matrix receiver in sequential order. The selected input source will be displayed
on the LED of INPUT CHANNEL.
Method B1: IR remote control for switching input channels
Please decide which input channel to be selected by pressing Source Selection 1 to Source
Selection 8. Or you can use left
—
and right
«
button to enter IR control mode and select
the input channel in ascending and descending order respectively. The setting will be effective
in a couple of seconds.
Note
Right ( ) button to switch input source in ascending order (1, 2, 3, 4, 5, 6, 7, 8, 1, 2, ......)
Left ( ) button to switch input source in descending order (1, 8, 7, 6, 5, 4, 3, 2, 1, 2, ......)
Method B2: IR remote control for controlling HDMI
™
sources
Users can use the corresponding IR remotes to control respective BD players, DVD players, or any
HDMI
™
input devices including AT-HD88M-SR itself with IR control at any display site.
Switch input port in descending order
*
«
Switch input port in ascending order
*
SOURCE SEL. 1
Switch the display channel at the
remote site to input port 1
SOURCE SEL. 2
Switch the display channel at the
remote site to input port 2
SOURCE SEL. 3
Switch the display channel at the
remote site to input port 3
SOURCE SEL. 4
Switch the display channel at the
remote site to input port 4
SOURCE SEL. 5
Switch the display channel at the
remote site to input port 5
SOURCE SEL. 6
Switch the display channel at the
remote site to input port 6
SOURCE SEL. 7
Switch the display channel at the
remote site to input port 7
SOURCE SEL. 8
Switch the display channel at the
remote site to input port 8
«
«
—
—
