PACKAGE CONTENTS
FEATURES
 State-of-the-art Silicon Image (Founder of HDMI ™ ) chipset embedded for upmost compatibility
and reliability
 HDMI ™ 1.3c compliant
 HDCP ™ compliant
 Allows any source to be displayed on multiple displays at the same time
 Allows any HDMI ™ display to view any HDMI ™ source at any time
 Supports 7.1 channel digital audio
 Supports default HDMI ™ EDID and learns the EDID of displays
 The matrix master can switch every output channels to any HDMI ™ inputs by push-in button,
IR remote control, or RS-232 control
 Allows controlling local HDMI ™ sources such as DVD and TiVo by IR extender through control
path at remote receiver
 Allows to control main matrix center through control line at remote receiver
 Extends video signal up to 35m (115 feet) over CAT5e at 1080p and likely longer with better
HDMI ™ source device (such as PS3), and better quality solid CAT6 cable *
 Easy installation with rack-mounting and wall-mounting designs for master and receiver
respectively
 Fast response time – 2~5 seconds for channel switch
* The length depends on the characteristics and quality of the cables. Higher resolutions and
longer transmission distances require low skew cables (<25ns/100m) for best performance.
Unshielded CAT6 with metal RJ-45 connectors is recommended.
 1x AT-HD88M-S (sender unit)  2x 1RU rack-mount ear
 8x AT-HD88M-R (receiver unit)  16x Wall-mount screws
 1x IR blaster  1x Installation CD
 8x IR receiver  1x UL AC C13 power cord
 8x IR remote control  1x User's manual
