6.3.4. Addressing
ADDRESS selector
It sets address of the interface from 0 to 7. Address identifies interface in the chain.
Up to (8) soundCUE interfaces can be installed in one system. The address selector identifies
interface by setting it to position 0 to 7. The ADDRESS must be set to different value on each
soundCUE in one system.
Address of
ADDRESS Selector
OUTPUT 1 and 3
OUTPUT 2 and 4
0
1 2
1
3 4
2
5 6
3
7 8
4
9 10
5
11 12
6
13 14
7
15 16
6.4. Setup by DIP Switch...................................................
DIP-8 switch on the bottom side of the interface is not used and it is prepared for the future use.
