Introduction
ViewCheck on ATCA-7370 Installation and Use (6806800S48B)
14
You can access ViewCheck using the following interfaces.
CLI
XML
Using these interfaces, you can
Initiate a diagnostic test
Query available diagnostic tests
Query status of a particular diagnostic test
Start and stop monitoring
Stop a diagnostic test
1.2.1
CLI
CLI is one of the interfaces provided to access the ViewCheck capabilities on the blade. Using
CLI, you can start, stop, and query kind of primitives at this prompt. The ViewCheck CLI can be
accessed via a console using SSH (or) Serial over LAN (SOL).
Blade Services Framework, a proprietary service of Artesyn, is used to provide the CLI access to
ViewCheck service. BSF binaries are provided along with the ViewCheck binaries.
For more information on BSF RPMs and Installation procedures, refer
1.2.2
XML
XML is also one of the primary interfaces to access ViewCheck capabilities on the blade. XML
interface supports methods, classes, and event notification mechanism. Using XML, you can
start, stop, query, and configure the parameters related to tests and monitors. XML interface
can be accessed in the same manner as CLI and is provided by BSF.
