Using HPI-B
System Management Interface Based on BBS HPI-B 2.0 (Centellis 4620/4440) User’s Guide (6806800P21D) 55
4.6.3 POST Type Control
This HPI control allows you to set/get the Power-On Self Test (POST) type of the blade. Two
POST types are configurable: long POST and short POST. Refer to the respective hardware user
manual of the blade for details about both POST types. The definition of the respective HPI
controls is given in the following tables.
Table 4-14 POST Type HPI Control RDR
SaHpiRdrT Value Notes
RecordId
Assigned by HPI implementation Unique identifier for
the RDR
RdrType SAHPI_CTRL_RDR
RdrTypeUnion.CtrlRec.Num MOTHPI_CTRL_NUM_POSTTYPE
RdrTypeUnion.CtrlRec.Outp
utType
SAHPI_CTRL_OEM
Indicates that this
control does not
correlate to any of the
given control output
types, and describes a
generic control
output.
RdrTypeUnion.CtrlRec.Type SAHPI_CTRL_TYPE_DISCRETE
RdrTypeUnion.CtrlRec.Tyoe
Union.Discrete.Default
0x0
RdrTypeUnion.CtrlRec.Oem Assigned by HPI
implementation
IdString MOTHPI_CTRL_NAME_POSTTYPE
Table 4-15 POST Type HPI Control Sate Values
SaGPISateT Value Notes
Type SAHPI_CTRL_TYPE_DISCRETE
