127
7
BIOS Setup
Super IO Configuration
This section is used to confi gure the I/O functions supported by the onboard
Super I/O chip.
Allows BIOS to select
Serial Port1 Base
Addresses.
BIOS SETUP UTILITY
v02.61 (C)Copyright 1985-2006, American Megatrends, Inc.
 Select Screen
 Select Item
+- Change Option
F1 General Help
F10 Save and Exit
ESC Exit
Confi gure Win627DHG-P Super IO Chipset
Serial Port1 Address
Serial Port2 Address
Serial Port2 Mode
PWRON After PWR-Fail
Confi gure Secondary Fintek F812116D Super IO Chipset
Serial Port3 Address
Serial Port3 IRQ
Serial Port4 Address
Serial Port4 IRQ
Serial Port5 Address
Serial Port5 IRQ
Serial Port6 Address
Serial Port6 IRQ
Advanced
[3F8/IRQ4]
[2F8/IRQ3]
[Normal]
[Former-Sts]
[3E8]
[11]
[2E8]
[10]
[2F0]
[11]
[2E0]
[10]
Serial Port1 Address and Serial Port2 Address
3F8/IRQ4, 2E8/IRQ3, 3E8/IRQ4
Selects the COM port’s base address.
Disabled
Disables the COM port.
Serial Port 2 Mode
COM port functions as a serial port or IrDA. You cannot use both at the same
time.
Normal
Sets the COM port to serial port mode.
IrDA
Sets the COM port to IrDA mode.
ASK IR
Sets the COM port to ASK IR mode.
Sets the COM port to ASK IR mode.
PWRON After PWR-Fail
Allows you to manually select an I/O address for the onboard serial port.
Note: Serial Port3 Address to Serial Port6 Address can be adjusted only with the following models
EC200/210/220/221-LR6G60 and EC200/210/220/221-LR6880. It does not support for EC200/210/220/221-
LRA060.
