DFI CR902-B - Manual (Page 46)

www.dfi .com Chapter 4 BIOS Setup
46
Chapter 4
Security
Administrator Password
Sets the administrator password.
User Password
Sets the user password.
Set Administrator
Password.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1227. Copyright (C) 2012 American Megatrends, Inc.
Password Description
If ONLY the Administrator’s password is set,
then this only limits access to Setup and is only
asked for when entering Setup.
If ONLY the User’s password is set, then this
is a power on password and must be entered to
boot or enter Setup. In Setup the User will have
Administrator rights.
The password length must be
in the following range:
Minimum length 3
Maximum length 20
Administrator Password
User Password
Save & Exit Chipset Advanced Main Boot Security
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
F4: Save and Reset
ESC: Exit
Save & Exit
Save Changes and Reset
To save the changes, select this field and then press <Enter>. A dialog box will ap-
pear. Select Yes to reset the system after saving all changes made .
Discard Changes and Reset
To discard the changes, select this field and then press <Enter>. A dialog box will
appear. Select Yes to reset the system setup without saving any changes.
Restore Defaults
To restore and load the optimized default values, select this field and then press
<Enter>. A dialog box will appear. Select Yes to restore the default values of all the
setup options.
Save as User Defaults
To save changes done so far as user default, select this field and then press <En-
ter>. A dialog box will appear. Select Yes to save values as user default.
Restore User Defaults
To restore user default to all the setup options, select this field and then press <En-
ter>. A dialog box will appear. Select Yes to restore user default.
Reset the system after
saving the changes.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1227. Copyright (C) 2012 American Megatrends, Inc.
Save Changes and Reset
Discard Changes and Reset
Restore Defaults
Save as User Defaults
Restore User Defaults
Boot Override
SATA SM: ATAPI iHAS324 Y
SATA PM: ST3160812AS
Chipset Advanced Main Boot Security Save & Exit
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
F4: Save and Reset
ESC: Exit
