www.dfi .com Chapter 4 BIOS Setup
41
Chapter 4
WatchDog Configuration
WatchDog1 function
This field is used to enable or disable the Watchdog timer function.
Enable/Disable IT8518
WatchDog Timer.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
WatchDog1 function
Advanced
[Disabled]
Intel(R) Ethernet Network Connection i217-LM - 88:88:88:...
This section is used to configure the parameters of Gigabit Ethernet device.
Click to confi gure the
network device port.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
PORT CONFIGURATION MENU
 NIC Confi guration
Blink LEDs (range 0-15 seconds)
PORT CONFIGURATION INFORMATION
UEFI Driver:
Adapter PBA:
Chip Type:
PCI Device ID
PCI Bus: Device: Function:
Link Status
Factory MAC Address:
Advanced
0
Intel(R) 1GbE DEV 5.1.00
FFFFFF-OFF
Intel PCH LPT
153A
0:25:0
[Disconnected]
88:88:88:88:87:88
NIC Configuration
This field is used to configure the network device.
Blink LEDs
Blink LEDs for the specified duration (up to 15 seconds).
Link Status
This field indicates the link status of the network device.


Enter:
+/-:
F1:
F2:
F3:
F4:
ESC:
Select Screen
Select Item
Select
Change Opt.
General Help
Previous Values
Optimized Defaults
Save and Reset
Exit


Enter:
+/-:
F1:
F2:
F3:
F4:
ESC:
Select Screen
Select Item
Select
Change Opt.
General Help
Previous Values
Optimized Defaults
Save and Reset
Exit
