www.dfi .com Chapter 1 Introduction
6
Expansion
Interfaces
• Supports 8 USB 2.0 interfaces
• Supports 1 PCIe x16 Gen 3 interface
• Supports 6 PCIe x1 interfaces
• Supports 4 PCI interfaces (PCI 2.3)
• Supports LPC interface
• Supports SMBus interface
• Supports I 2 C interface
• Supports IDE interface
• Supports 4-bit input and 4-bit output GPIO
IDE Interface • Supports up to two IDE devices
• DMA mode: Ultra ATA up to 100MB/s
Intel ® Active
Management
Technology -
AMT
(HM920-QM87)
• Supports iAMT9.0
• Out-of-band system access
• Remote troubleshooting and recovery
• Hardware-based agent presence checking
• Proactive alerting
• Remote hardware and software asset tracking
Damage Free
Intelligence
• Monitors CPU temperature and overheat alarm
• Monitors CPU fan speed and failure alarm
• Monitors Vcore/1.05V/DDR voltages and failure alarm
BIOS • AMI BIOS
- 64Mbit SPI BIOS
WatchDog
Timer
• Software programmable from 1 to 255 seconds
OS Support • Windows XP Professional x86 & SP3 (32-bit)
• Windows 7 Ultimate x86 & SP1 (32-bit)
• Windows 7 Ultimate x64 & SP1 (64-bit)
• Windows 8 Enterprise x86 (32-bit)
• Windows 8 Enterprise x64 (64-bit)
(based on Intel's Windows XP support list)
Temperature • Operating: 0 o C to 60 o C
• Storage: -20 o C to 85 o C
Humidity • 5% to 90%
Power • Input: 12V, VCC_RTC, 5VSB* (optional)
Power
Consumption
• TBD
PCB • Dimensions
- COM Express ® Basic
- 95mm (3.74") x 125mm (4.9")
• Compliance
- PICMG COM Express ® R2.1, Type 2
Chapter 1 - Introduction
Specifications
Processor • 4th generation Intel ® Core TM processors
4700EQ: Intel ® Core TM i7-4700EQ, 6M Cache, up to 3.4 GHz, 47W
4400E: Intel ® Core TM i5-4400E, 3M Cache, up to 3.3 GHz, 37W
4402E: Intel ® Core TM i5-4402E, 3M Cache, up to 2.7 GHz, 25W
4100E: Intel ® Core TM i3-4100E, 3M Cache, 2.4 GHz, 37W
4102E: Intel ® Core TM i3-4102E, 3M Cache, 1.6 GHz, 25W
2000E: Intel ® Celeron ® 2000E, 2M Cache, 2.2 GHz, 37W
2002E: Intel ® Celeron ® 2002E, 2M Cache, 1.5 GHz, 25W
• BGA 1364 packaging technology
• 22nm process technology
Chipset • Intel ® QM87 Express Chipset (HM920-QM87)
• Intel ® HM86 Express Chipset (HM920-HM86)
System Memory • Two 204-pin DDR3L SODIMM sockets
• Supports DDR3L 1333/1600MHz SODIMM
• Supports up to 16GB system memory
• DRAM device technologies: 1Gb, 2Gb and 4Gb DDR3L DRAM technologies are
supported for x8 and x16 devices, unbuffered, non-ECC
Graphics • Intel ® HD Graphics 4600
• Supports 1 VGA and 1 LVDS
• VGA: resolution up to 2048x1536 @60Hz
• LVDS: NXP PTN3460, 24-bit, dual-channel, resolution up to 1920x1200 @60Hz
• Intel ® Clear Video Technology
• Intel ® Advanced Vector Extensions (Intel ® AVX) Instructions
• Supports DirectX 11.1, OpenGL 3.2, OpenCL 1.2
Audio • Supports High Defi nition Audio interface
LAN • Intel ® I217LM with iAMT9.0 Gigabit Ethernet Phy (HM920-QM87)
• Intel ® I217LM Gigabit Ethernet Phy (HM920-HM86)
• Integrated 10/100/1000 transceiver
• Fully compliant with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Serial ATA HM920-QM87:
• Supports 4 SATA 3.0 with data transfer rate up to 6Gb/s
• Integrated Advanced Host Controller Interface (AHCI) controller
• Supports RAID 0/1/5/10
• Supports Intel ® Smart Response Technology
HM920-HM86:
• Supports 2 SATA 3.0, 1 SATA 2.0, and 1 IDE
• Supports 2 SATA 3.0, 1 IDE, and 1 SSD* (optional)
• Integrated Advanced Host Controller Interface (AHCI) controller
SSD* (optional) • 2GB/4GB/8GB/16GB/32GB/64GB
• Write: 30MB/sec (max), Read: 70MB/sec (max)
• SATA to SSD onboard
Trusted
Platform
Module - TPM*
(optional)
• Provides a Trusted PC for secure transactions
• Provides software license protection, enforcement and password protection
Chapter 1
Note:
*Optional and is not supported in standard model. Please contact your sales represen-
tative for more information.
