PCI Express Configuration
PCI Express Root Port 1
Settings.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
PCI Express Confi guration
 PCI Express Root Port 1
 PCI Express Root Port 2
 PCI Express Root Port 3
 PCI Express Root Port 4
 PCI Express Root Port 5
 PCI Express Root Port 6
 PCI Express Root Port 7
PCIE Port 8 is assigned to LAN
Chipset
PCI Express Root Port 1 to PCI Express Root Port 7
Control the PCI Express Root Port.
Control the PCI Express
Root Port.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
PCI Express Root Port 1
ASPM Support
 PME SCI
Hot Plug
PCIe Speed
Chipset
[Enabled]
[Disabled]
[Enabled]
[Disabled]
[Gen1]
ASPM Support
Set the ASPM level. The options are listed as below:
Force L0s Forces all links to L0s State.
Auto The BIOS automatically select an ASPM level.
Disabled Disables ASPM.
PME SCI
Enable or disable PCI Express PME SCI.
Hot Plug
Enable or disable PCI Express port as Hot Plug.
PCIe Speed
Select the speed of PCI Express port. The option is Gen1 or Gen 2.


