Chapter 2 Hardware Installation
Chapter 2
Battery
Battery
Standby Power LED
This LED will light red when the system is in the standby mode. It indicates that there is pow-
er on the system board. Power-off the PC and then unplug the power cord prior to installing
any devices. Failure to do so will cause severe damage to the motherboard and components.
Standby Power LED
The lithium ion battery powers the real-time clock and CMOS memory. It is an auxiliary source
of power when the main power is shut off.
Safety Measures
• Danger of explosion if battery incorrectly replaced.
• Replace only with the same or equivalent type recommend by the manufacturer.
• Dispose of used batteries according to local ordinance .
Connect to the
battery connector Battery
1
+3.3V GND
2
