Chapter 3 BIOS Setup
Chapter 3
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
PCI Express Confi guration
PCI Express Port 0
Speed
PCI Express Port 1
Speed
PCI Express Port 2
Speed
PCI Express Port 3
Speed

[Enabled]
[Auto]
[Enabled]
[Auto]
[Enabled]
[Auto]
[Enabled]
[Auto]
Chipset
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
PCI Express Configuration
This section configues settings relevant to PCI Express devices.
Enable or Disable the
PCI Express Port 0 in the
Chipset
PCI Express Port 0-3
Enable or disable the PCI Express port in the chipset.
Speed
Select the speed for the PCI Express devices. The options are Auto, Gen1 or Gen2.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Audio Confi guration
Audio Controller
Azalia HDMI Codec
DP/HDMI Port B 
[Enabled]
[Enabled]
[Disabled]
Chipset
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
Azalia HD Audio
This section configues Azalia HD Audio options.
Control Detection of the
Azalia device. Disabled =
Azalia will be uncondition-
ally disabled. Enabled =
Azalia will be uncondition-
ally enabled. Auto = Azalia
will be enabled if present
disabled otherwise.
Audio Controller
This item controls the detection of the Azalia device.
Disabled
Azalia will be unconditionally disabled.
Enabled
Azalia will be unconditionally enabled.
Auto
Azalia will be enabled automatically.
Azalia HDMI Codec
Enable or disable the internal HDMI codec for Azalia.
DP/HDMI Port B
Enable or disable the DP/HDMI Port B.
