Chapter 3 BIOS Setup
Chapter 3
HW Monitor
This section is used to monitor the hardware status.
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
HW Monitor
 Smart Fan Function
Case Open
Restore AC Power Loss
System temperature
CPU temperature
System Fan Speed
CPU Fan Speed
VCORE
5V
12V
VDDQ
Advanced
[Disabled]
[Power Off]
: +35 C
: +30 C
: 0 RPM
: 7219 RPM
: +0.920 V
: +5.116 V
: +12.000 V
: +1.348 V
Smart Fan Function Setting
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
CPU Smart Fan Control
When this feature is set to Automatic, the CPU’s fan speed will rotate according to the
CPU’s temperature. The higher the temperature, the faster the speed of rotation.
Smart Fan Function
Aptio Setup Utility - Copyright (C) 2013 American Megatrends, Inc.
Version 2.16.1242. Copyright (C) 2013 American Megatrends, Inc.
Smart Fan Function
CPU Smart Fan Control
Boundary 4
Boundary 3
Boundary 2
Boundary 1
Speed Count 5
Speed Count 4
Speed Count 3
Speed Count 2
Speed Count 1
System Smart Fan (1) Control
Boundary 4
Boundary 3
Boundary 2
Boundary 1
Speed Count 5
Speed Count 4
Speed Count 3
Speed Count 2
Speed Count 1
Advanced
[Enabled]
60
50
40
30
100
75
50
40
30
[Enabled]
60
50
40
30
100
75
50
40
30
Enable CPU Smart Fan
 Select Screen
 Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized Defaults
F4: Save & Reset
ESC: Exit
System Smart Fan Control
When this feature is set to Automatic, the system’s fan speed will rotate according to
the system’s temperature. The higher the temperature, the faster the speed of rotation.
Boundary 1 to Boundary 4
The range is 0-127.
Speed Count 1 to Speed Count 5
The range is 1-100%.
Case Open
Sets this field to Enabled to allow the system to alert you of a chassis intrusion event.
Restore AC Power Loss
Power Off
When power returns after an AC power failure, the system’s power is off. You must
press the Power button to power-on the system.
Power On
When power returns after an AC power failure, the system will automatically power-on.
Last State
When power returns after an AC power failure, the system will return to the state
where you left off before power failure occurs. If the system’s power is off when AC
power failure occurs, it will remain off when power returns. If the system’s power is on
when AC power failure occurs, the system will power-on when power returns.
