Manual Override Test Testing
Manual Override Test
Upon completion of the system wiring, the pumps and/or dispensers should be tested to verify
that the AC wiring is correct. Do not turn on the system power during these tests. The
appropriate procedure for testing and the expected results is provided below. Should any of
these tests fail, the wiring should be corrected and the test must be performed again.
To perform the Manual Override Test, proceed as follows:
1 Turn off all the system override switches.
2 Turn on the breakers for all the pumps/dispensers.
3 Place the system override switch, located in the pedestal, for hose 1 in the MANUAL position.
4 Turn on hose 1. After completing the reset procedure, the hose should be able to dispense the
product.
5 Turn on all other hoses. No other hose besides 1 should be active.
6 Turn off all hoses.
7 Place the system override switch, located in the pedestal, for hose 1 in the OFF position.
8 Repeat steps 3 to 7 for all remaining hoses. Substitute the hose under test for hose 1.
