Collecting
When the printing and/or encoding cycle is completed,
the printed and/or encoded card will be returned into output
hopper which is designed with a capacity of 50 x 0.8mm cards.
Adjusting
The printer has a manual adjustable card thickness mechanism which can
be located inside the printer unit when the top cover is open. The thickness
level accepts from 0.3mm to 1.0mm, and the factory setting is at 0.8mm.
a. Open the top cover.
b. Adjust the thickness level by moving the lever from left to right to the preferred thickness setting.
c. Close the top cover.
09
English
a c b
Card thickness adjustor
