1.3 Installation
1.3.1 Ribbon Installing
a. Open the top cover.
b. Place the ribbon ID key into ID key socket.
c. Insert the ribbon as shown.
a b c d
d. Close the top cover slowly and press until a click sound is heard.
06
Using the original HiTi CS Card Printer Ribbon consumables will optimize your printer’s performance and
avoid causing damages to it. Use of non HiTi original consumables will void the manufacturer’s warranty
policy for the printer.
English
Please ensure your ribbon format is corresponded to installed ribbon ID key’s label.
Please make sure your ribbon film is facing top side during installation and also ensure the color
of ribbon spool/core is matching to the ribbon adapter/holder.
To optimize printing quality, please engage in printer cleaning every time when the ribbon is changed.
HiTi CS-200e & CS-220e user manual
