25
Ribbon Types
Options
(Easy Add Modules)
General Information
Warranty
400 cards high capacity input hopper
Flipper module
Magnetic encoding module (ISO 7811 HiCo/LoCo or JIS2 magnetic strip encoder)
Smart IC encoding module (ISO 7816-2 / PC/SC, EMV 2000-1)
Contactless/RFID encoding module (ISO 14443A, B, ISO 15693, Mifare, DesFire, HID iCLASS)
Ethernet connection module
Vary from region to region, please consult with your local distributor or reseller for details
Card types: PVC card
Card format: ISO CR-80 / ISO 7810 (53.98mm x 85.60mm)
Card thickness:
*0.3mm ~1.0mm (10mil ~ 40mil); dual-sided printing workable from 0.5mm to 1.0mm (20mil ~ 40mil)
*0.3mm = 0.25mm round off to 1
st decimal place
Input card feeder capacity: 100 cards (0.8mm/30mil)
Output hopper capacity: 50 cards (0.8mm/30mil)
Printer dimensions: 197.8mm (W) x 354mm (L) x 204mm (H)
Weight: 4.9kg
Connections: USB port, Ethernet TCP/IP port as an option (Ethernet 10/100 Mbps)
Power supply: AC input: 100~240V~2.5A, 50~60Hz / DC output: 24V = 4.16A
Operating environment: +15ºC to +32ºC / 20% to 85% RH (without condensation)
Storage environment: -20ºC to +60ºC / 20% to 90%RH (without condensation)
Operating ventilation: open cooled air area
English
HiTi CS-200e & CS-220e user manual
Full panel YMCKO color ribbon: 400prints/roll
1/2 panel YMCKO color ribbon: 560prints/roll
Full panel YMCKOK color ribbon:330prints/roll
YMCKFoO color ribbon:165prints/roll
KO ribbon:500prints/roll
Monochrome Resin Black :1000prints/roll
