Illustration for manual removal
card jams:
Twist clockwise
Flathead
screwdriver
22
4.3.2 Releasing from card jams
You can also perform the following steps to prevent card jams:
Open the printer cover door
Remove the ribbon
Follow the instruction on the LCM control panel with three options: Auto removal, Semi-auto removal
and Manual removal
Check the card thickness settings is correctly adjusted from the
printer driver option and thickness gauge
Check the card thickness is fitted under specified specification
in this manual
Check the cards are flat in horizontal position
Check the cards are not stuck together, and shuffle cards is
required before loading
Please remove the jammed card by the following instruction displayed on LCM control panel of the printer
before continuing the printing job.
During semi-auto removal and manual removal process, please do not put your hands into the
card printer.
