PCI-DAS6013 and PCI-DAS6014 User's Guide Installing the PCI-DAS6013 and PCI-DAS6014
12
Connecting the board for I/O operations
Connectors, cables – main I/O connector
The table below lists the board connectors, applicable cables, and compatible accessory products for the PCI-
DAS6013 and PCI-DAS6014.
Board connectors, cables, and accessory equipment
Connector type Shielded, SCSI 100-pin D-type
Compatible cables C100HD50-x unshielded ribbon cable. x = 3 or 6 feet. (see Figure 1)
C100MMS-x cable shielded round cable. x = 1, 2, or 3 meters (see Figure 2)
Compatible accessory products
(with the C100HD50-x cable) ISO-RACK16/P
ISO-DA02/P (PCI-DA6014 only)
BNC-16SE
BNC-16DI
CIO-MINI50
CIO-TERM100
SCB-50
Compatible accessory products
(with the C100MMS-x cable) SCB-100
