PCI-DAS6013 and PCI-DAS6014 User's Guide Installing the PCI-DAS6013 and PCI-DAS6014
16
Field wiring and signal termination
The following Measurement Computing accessory boards can be used with the PCI-DAS6013 and PCI-
DAS6014:
Screw terminal boards and BNC adapters :
Use with the C100HD50-x cable:
 CIO-MINI50 – 50-pin universal screw terminal accessory.
 CIO-TERM100 – 16x4 screw terminal.
 SCB-50 – 50 conductor, shielded signal connection/screw terminal box provides two independent 50-pin
connections.
Use with the C100MMS-x cable:
 SCB-100 – 100 conductor, shielded signal connection/screw terminal box provides two independent 50-pin
connections.
BNC connector boxes :
 BNC-16SE – 16-channel single-ended BNC connector box.
 BNC-16DI – Eight-channel differential BNC connector box.
Details on these products are available on our web site at www.mccdaq.com/products/screw_terminal_bnc.aspx .
ISO-5B module racks :
 ISO-RACK16/P – 16-channel isolation module mounting rack.
 ISO-DA02/P (PCI-DA6014 only) – Two-channel, 5B module rack.
Details on these products are available on our web site at www.mccdaq.com/products/signal_conditioning.aspx .
