Installing Optional Speckled Stones
[RR300SS]
Once the glass door has been removed as shown in
the previous section, place the speckled stones evenly
across the pan and burner. Ensure stones do not
overlap too much as this will effect the flame pattern,
see figure 25. DO NOT cover the pilot with stones, see
figure 25a.
Figure 25. Evenly placed speckled stones
Figure 25a. Ensure the stones DO NOT cover the pilot.
If the firestones are not placed properly (ONE LAYER ONLY),
on burners excessive sooting will result. The firestones will
get very hot while the fireplace is in operation, and should
not be handled until cool.
Figure 24d. Completed firestone installation.
Figure 24e. Completed firestone installation. (Note: DO NOT
place ANY firestones on top of the pilot cover).
Figure 24f. Gas fireplace with firestones.
CAUTION!
If the pilot cover is covered with firestones it may result in
delayed ignition and/or damage to the appliance and/or
surrounding property.
WARNING!
