C3X 1080
ENGLISH
21
14 TEChNICAL SPECIfICATIONS
ELECTRONICS
Input signals:
• COMPOSITE VIDEO (CVBS)
gold plated RCA connectors
1,0 V
pp
/ 75 Ω, negative synchronisation
• 1 S-VIDEO (Y/C)
4-pole mini-DIN connector
Y: 1.0 V
pp
/ 75 Ω, negative synchronisation
C: 0.286 V
pp
/ 75 Ω, [ nominal NTSC burst level]
0.3 V
pp
/ 75 Ω [nominal PAL, SECAM burst level]
• 1 COMPONENTS (Y/Pr/Pb/) - RGBS
1 set of 4 RCA connectors
- Component signals
Y: 1.0 V
pp
/ 75 Ω, negative or 3 level synchronisation [HDTV]
Pr,Pb:0.7 V
pp
/ 75 Ω
- RGB signal
R,B:0.7 V
pp
/ 75 Ω
G: 0,7 V
pp
/ 75 Ω, HV synchronisation
1.0 V
pp
/ 75 Ω, negative or 3 level synchronisation [HDTV]
Positive or negative TTL, 0.3-5 V
pp
/ 1 kΩ
• 1 RGBHV (analogue RGB)
female DB15HD connectors
R,B: 0.7 V
pp
/ 75 Ω
G: 0.7 V
pp
/ 75 Ω, separate H/V Sync or H+V Sync
1.0 V
pp
/ 75 Ω, negative or 3 level synchronisation [HDTV]
Positive or negative TTL, 0.3-5 V
pp
/ 1 kΩ
• 2 DIGITAL HDMI
Control:
keypad on rear input panel, remote con-
trol
RS232 from PC,
home automation devices,
USB 1.1
Horizontal frequency:
from 15 to 80 kHz (up to to UXGA format
@ 65 Hz)
Vertical frequency:
48 -100 Hz
Video Standard:
automatic selection (PAL
B,G,H,I,M,N,60, SECAM, NTSC 3.58
and 4.43)
High definition video standard: ATSC HDTV (480p, 720p, 1080i, 1080p)
Graphic standards:
VGA, SVGA, XGA, SXGA, UXGA
Colour temperature:
from 5500 to 9000 K (36 steps)
Outputs:
2 12-V jack connector outputs (1 active
with system powered on, 1 active with
16:9 aspect ratio selected)
Vertical shift:
+ 50% image
gENERAL:
Mains cable:
(EU, UK and US); 2m length
Mains:
from 110 to 240 Vac (3,8-1,5 A)
Frequency: from 50 to 60 Hz
350 W max
Fuse:
T 5.A H 250V 5 x 20 mm
Dimensions:
435 x 190 x 430 mm (LxAxP)
Weight (approx):
11 kg
Operating temperature:
10 to 35°C
Shipping temperature:
-15 to 55°C
Storage temperature:
-15 to 55°C
Humidity:
20% to 95% humidity nonconden-
sing
Safety:
EN 60950
Portablity:
desktop equipment
Safety:
EN 55022 Class B
EN 55024 - EN 61000-3-2 EN
61000-3-3
UL approval in progress
Transport:
IEC 68-2-31, IEC 68-2-32
