Cameras and Frame Grabbers Tested
with Thinklogical
®
Camera-Link Extender
Manufacturer
Model
Bits/pixel
Taps
Clock
(MHz)
Basler
L103k
8 or 10
2
20 per tap
Basler
L301KC/F
8 or 10
1
60
Basler
A202K
10
2
40
Basler
A404K
8 or 10
8
50
Basler
A501k
8
1
50
Basler
A504KC
8
10
67
Cohu
7700
10
1
40
Cohu
7800
8
1
40
Cohu
7900
10
1
40
Chromasens
Aleos MCS 1k
8
1
60
Chromasens
Aleos MCS 2k
8
1
60
Chromasens
Aleos MCS 4k
8
1
60
Chromasens
Aleos MCS 7k
8
1
60
Dalsa
Dalstar DS-21-02M30
8 or 10
2
40 per tap
Dalsa
Dalstar DS-22-2M30
8 or 10
2
40 per tap
Dalsa
Falcon 1.4M100
8 or 10
2
80
Dalsa
Piranha2 P2-2X
8 or 10
2
40 per tap
Dalsa
Piranha Color 2K and 4K
24 or 36
3, 4, or 6
60 or 80
Dalsa
P2-4x-08k40
8 or 10
4
40
Dalsa
HS-40-04K40
8,12
4
40
Dalsa
HS-80-08K40
8,12
8
40
Dalsa
HS-80-08K80
8,12
8
40
Dalsa
HS-4X-02K30
8,10
4
30
Dalsa
Pantera SA 2M30 Camera
DS-21-02M30 (1600x1200,
mono)
8 or 10
2
40
Dalsa
Pantera SA 2M30 Camera
DS-22-02M30 (1600x1200, color)
8 or 10
2
40
Dalsa
Pantera SA 2M30 Camera
DS-24-02M30 (1920x1080,
mono)
8 or 10
2
40
Dalsa
Pantera SA 2M30 Camera
DS-25-02M30 (1920x1080, color)
8 or 10
2
40
Dalsa
Pantera SA 4M15 Camera
DS-2x-04M15
8 or 10
2
40
Dalsa
Pantera TF DS-21-01M60
8,10,12
2
40
Dalsa
Pantera TF DS-1A-01M30
8,10,12
1
40
Dalsa
Pantera TF 11M4 PT-2x-11M04
8,10,12,14
2
36
Dalsa
Pantera TF 6M8 PT-2x-06M08
8,10,12,14
2
36
