PB200 WeatherStation User Manual revision 1.000
Proprietary and Confidential
63
ID Description Failure Codes
11 Standard relative humidity sensor 0x01 = Humidity sensor fault: no frequency
0x02 = Humidity sensor fault: frequency too high
0x03 = Humidity sensor fault: frequency too low
0x04=0xEF = reserved
12 Barometric pressure sensor 0x01 = Sensor fault
0x02-0xEF = reserved
13 Wind sensor 0x01 = Sensor fault
0x02-0xEF = reserved
14 Compass sensor 0x01 = Sensor fault
0x02-0xEF = reserved
15 GPS receiver 0x01 = Fault
0x02-0xEE = reserved
0xEF = Test results not yet available
16 Attitude sensor 0x01 = Sensor fault
0x02-0xEF = reserved
17 Rate gyro 0x01 = Sensor fault
0x02-0xEF = reserved
18 Optional Galltec relative humidity sensor 0x01 = Sensor fault
0x02-0xEE = reserved
0xEF = Sensor not present
2.5. Received NMEA 2000® PGNs
The NMEA 2000® PGNs recognized by the PB200 WeatherStation are summarized in Table 2. Each of the PGNs in Table 2 is described in detail
on the subsequent pages.
Table 2: NMEA 2000® Received PGNs
PGN Description
59904 ISO Request
