Line pairs in the P_Active line category can be reserved for carrying data
by configuring Data Line Pairs with local or remote controls. Refer to
for a listing of the Data Line Pairs lines that are available with each
setting.
Programmable VBI and Active Picture Lines
The programmable lines in the vertical blanking interval include the con-
figurable VBI lines (CVBI). Configurable active picture lines (P_Active) can
be reserved for carrying data (refer to
These line pairs can be configured for the following:
•
Blank – in local mode, select On to blank all lines of CVBI or Off to not
blank. In remote mode, lines can be blanked or passed on a line-by-line
basis with the web page (toothed blanking).
Video Processing Adjustments
The controls for video processing on each channel are the following:
•
Test signal generator – when enable, sends the internal test signal gen-
erator 75% Color Bars test signal to the channel output.
Note
When the internally generated color bars test signal output is enabled, the rel-
ative sync and burst may be offset in relation to the input SDI stream timing.
•
EDH Insertion – insertion of new EDH can be enabled or disabled
(input EDH is always removed).
•
HANC – horizontal ancillary data (including embedded audio) may be
passed or blanked.
Reference Input Sync
The module is locked to the reference input sync. The following reference
input sync considerations should be noted:
•
Jitter performance of the module is influenced by the time base jitter of
the reference input sync.
Table 4. Lines Reserved for Carrying Data
525 Line
Selection
Data Line Pairs
Reserved
625 Line
Selection
Data Line Pairs
Reserved
None
None
None
None
21/284
21/284
24/337
24/337
22/285
21/284 – 22/285
25/338
24/337 – 25/338
23/286
21/284 – 23/286
26/339
24/337 – 26/339
24/287
21/284 – 24/287
27/340
24/337 – 27/340
28/341
24/337 – 28/341
