Specifications
Specifications
Table 8. 8964FS Specifications
Parameter
Value
SDI Inputs
Number of inputs
4, one for each channel
Signal type
Serial digital conforming to SMPTE 259M, 10-bit 270 Mb/s serial component
Connector type
75 Ω terminating BNC on rear of frame
Signal level
800 mV ± 10%
Return loss
> 15 dB, 5 to 270 MHz
Error checking
EDH monitored
SDI Outputs
Number of outputs
4, one for each channel
Signal type
Serial digital conforming to SMPTE 259M, 10-bit 270 Mb/s serial component
Connector type
75 Ω terminating BNC on rear of frame
Signal level
800 mV ± 10%
Return loss
> 15 dB, up to 270 MHz
DC offset
< 0.5 V when terminated in 75Ω
Jitter
< 400 ps above 1 kHz (conforms to SMPTE 17.12/002)
Rise/fall times
700 to 900 ps (20 to 80% amplitude)
Error checking
EDH inserted or blanked
Reference Input
Number of inputs
One
Signal type
Color black, SMPTE170M,140 mV to 560 mV, 525 or 625
Connector type
75 Ω BNC loop-through
Signal level
Video – 0.5 V p-p to 2 V p-p, 1 V p-p nominal with sync,
Pulse – 140 mV to 600 mV
Return Loss
> 40 dB to 5.0 MHz
Signal to noise requirement
> 40 dB
Timing
Range – Frame Sync
1 frame
Delay from reference, all timing
controls set to 0
625
525
4 lines + 55.90 µs
5 lines + 55.22 µs
Performance
Quantization
10-bit
Accuracy
9.2-bit EDH detection
Output phasing
Full frame
Cable length
250 M of 1694A cable
