Configuration
Table 7. Local Rotary and Paddle Switch Functions
Function
Switch
Setting
Paddle
Switch Up
Paddle
Switch Down
Function Description
OSD Text Summary
Bank 1 (2ND LED off)
Bank 1 (2ND LED off)
0
–
–
Default position for normal operation (parked)
Ch#, Channel Name 1:0 (bank/#)
Model #
HW ver x.x FW ver x.x
SN: xxxxxxxxxx
1
On
Off
Turn OSD (on screen display) on or off
Ch#, Channel Name 1:1
Video: rate or NO Ref: rate or NO
On screen disp: (current state)
Choices or scroll bar
2
–
–
Not used
3
On
Off
Enable new EDH insertion
1:3 EDH Inserter
4
Blank
Pass
Blank or pass HANC data
1:4 HANC DAta
5-B
–
–
Not used
C
On
Off
Turn output test signal generator on or off
1:C test Signal
D
–
–
Not used
E
>2s Learn
Recall
Hold paddle for more than 2 seconds to learn
current channel settings into E-MEM register.
Select down to Recall.
1:E >2s Learn
F
–
Recall
Recall factory defaults
1:F Factory default
Bank 2 (2ND LED on)
Bank 2 (2ND LED on)
0
–
–
Default position for normal operation (parked).
2:0 (parked position information)
1
None
21/284 or 24/337
Select P_Active lines to reserve for data (525
or625). See
2:1 Rsv for data
2
22/285 or 25/338
23/286 or 26/339
2:2 Rsv for data
3
24/287 or 27/340
28/341 (625 only)
2:3 Rsv for data
4
On
Off
Turn VBI blanking on or off (all VBI lines).
2:4 VBI Blank
5 – A
–
–
Not used
B
Increase
Decrease
Adjust horizontal timing
2:B Horizontal Timing
C
Increase
Decrease
Adjust vertical timing
2:C Vertical Timing
D
AutoBlue
Field 1
Select Freeze mode
2:D Frz Mode
E
Field 2
Frame
Select Freeze mode
2:E Frz Mode
F
AutoFrz
AutoBlue
Select Freeze mode: AutoFreeze
2:F Frz Mode: AutoFrz
