8985FSP/FS/PRC — Instruction Manual 73
Functional Description
A block diagram of the 8985PRC module is shown in Figure 37 .
Figure 37. 898PRC Block Diagram
Option
HD/SD
SDI in
SD/HD
Optical In
4X HD/SD
SDI Out
RX 2
Fiber
Receiver
RX 1
RGB Video
Proc Amp YUV Video
Proc Amp
Equalizer
