Installation and Operations Manual
CONTROL Center Control Unit:
Dimensions:.........................L: 18 in (45.72 cm)
H: 5.5 in (13.97 cm)
D: 8.5 in (21.59 cm)
Weight:...............................4.5 lbs (2.04 kg)
Display Type:.......................160x80 STN LCD with backlight
Display Dimensions:.............H:1.5 in (3.81 cm) W:3 in (7.62 cm)
AC Power:...........................US: 120 VAC~, 60Hz, 100W
INT: 100-240 VAC~, 50/60Hz, 100W
DC Power:...........................18-20 VDC A
Temperature Range:............32°- 100° F (0°-37.78° C)
Humidity Range:..................0-95% Non-condensing
RS-485 Ports:.......................In/Out
RS-485 Connector: ..............Modular handset (4-conductor)
RS-485 Distance: .................2500’ (762.2 m) Max
COM 1 (RS-232):.................DB9 Female
COM 1 Distance:.................50’ (15.2 m) Max
COM 2 (RS-232):.................DB9 Male
COM 2 Distance:.................50’ (15.2m) Max
CONTROL Center Switcher:
Dimensions:.........................L: 17.5 in (44.5 cm) H: 3.5 in (8.89 cm) D: 12.75 in (32.39 cm)
Weight:...............................13 lbs. (5.88 kg)
Power:.................................100-250 VAC~, 1.6 Amps, 50-60 Hz
Temperature Range:............32°- 100° F (0°-37.78° C)
Humidity Range:..................0-95% Non-condensing
Inputs:.................................8— 75 Ohms, Composite (BNC) or Y/C (mini-DIN)
Outputs:..............................3 Program— 75 Ohms, Composite (BNC) or Y/C (mini-DIN)
1 Preview— 75 Ohms, Composite (BNC) or Y/C (mini-DIN)
8 Blackburst— 75 Ohms, BNC
Sync Input:..........................1 looping— 75 Ohm, BNC
Video Performance:.............NTSC
75 Ohm impedance
55 MHz bandwidth
Audio Performance: ............Balanced Stereo
25K Ohm Input impedance/50K Ohm Output impedance
DC to 200 kHz bandwidth
Noise: less than .01% THD + N at line levels
19 dBm Headroom
“Phoenix”-type connectors
CCU (Camera Control Unit) – A device, external to the camera, that adjusts
video characteristics (detail, gains, pedestal, etc.).
Detail – Used to sharpen or soften a video image.
Gains – The level of the brightest areas of the video image. Gain may be
expressed as separate components of red, blue, and green.
Knee – Video compression at the brightest parts of a picture. The knee is used
to get as much detail as possible from very bright objects.
Linear Matrix – Color–correction circuitry used to adjust color without affecting
white balance.
Master Pedestal – Adjusts the darkness level of the black parts of the image.
Use this function to bring out details of heavily shaded areas.
Paint – Artificially coloring a video image to compensate for poor lighting or a
subject’s color characteristics. Also used to match the color of multiple cameras.
RS-485 – The protocol used by the CONTROL Center to communicate with the
CameraMan camera.
Tracking Views – Presets, stored by the CameraMan, that enable you to
change the presenter’s position in the autoTRACK frame.
White Balance – Matching of the red, green, and blue picture components to
achieve proper color hues.
Listed below are some key terms mentioned in this manual, as well as the specifications for the CONTROL Center. For the
specifications on your 1-CCD or 3-CCD camera, see the specifications section of the installation and operations manual that came
with the camera.
Specifications
Glossary
Appendix B: Glossary and Specifications
