Nomenclature
*
0
-
2
.
+
1
Lens hood mounting index (P. 22)
2
Rubber grip
3
Focus ring (P. 18)
4
Distance scale (P. 21)
5
Distance index line
6
Zoom ring (P. 21)
7
Focal length scale
8
Focal length scale index line
9
Tripod collar ring rotating index (P. 21)
0
Position indexes (90˚) (P. 21)
!
Tripod collar ring (P. 21)
@
Mounting index
#
Lens mount rubber gasket (P. 24)
$
CPU contacts (P. 24)
%
Lens hood (P. 22)
^
Lens hood setting index (P. 22)
&
Lens hood attachment index (P. 22)
*
Lens hood lock release button (P. 23)
(
Focus mode switch (P. 18)
)
Focusing limit switch (P. 19)
q
Vibration reduction ON/OFF switch (P. 20)
w
Vibration reduction mode switch (P. 20)
e
Tripod collar ring fastening screw (P. 21)
r
Tripod collar lock release lever (P. 22)
t
Tripod collar mounting foot (P. 21)
y
Tripod collar lock screw (P. 21)
u
Tripod collar (P. 21)
( ): reference page
