Detaching the hood
While holding down the lens hood lock release
button ( 1 ), turn the hood clockwise (as viewed
from the camera side) ( 2 , 3 ).
„ Recommended focusing screens
Various interchangeable focusing screens are available for certain
Nikon SLR cameras to suit any picture-taking situation. The ones
recommended for use with this lens are:
Screen EC-B
G1 G2 G3 G4
Camera
A B C E EC-E J L M U
F6
F5+DP-30
F5+DA-30 (-1.0)
◎
: Excellent focusing
○
: Acceptable focusing
Slight vignetting or moiré patterns appear in the viewfinder, but not
on the film.
— : Not available
( ): Indicates degree of exposure compensation needed (center-
weighted metering only). For F6 cameras, compensate by selecting
“Other screen“ in Custom Setting “b6: Screen comp.“ and setting
the EV level to -2.0 to +2.0 in 0.5 EV steps. When using screens
other than type B or E, “Other screen“ must be selected even when
the required compensation value is “0“ (no compensation required).
For F5 cameras, compensate using Custom Setting #18 on the
camera body.
See user's manual of the camera body for more details.
Blank box means not applicable. Since type M screen can be used for
both macro photography at a magnification ratio of 1:1 or above and
for photomicrography, it has different applications than other screens.
Important
• For F5 cameras, only EC-B, EC-E, B, E, J, A, L focusing screens are
usable in Matrix Metering.
• When using the B and E focusing screens in cameras other than those
listed above, refer to the columns for the B and E screens.
