[Input and output connectors]
A/V OUT (MONO) jack (Monaural) (DSC-P43
only)
Minijack
Video: 1 Vp-p, 75
Ω
, unbalanced,
sync negative
Audio: 327 mV (at a 47 k
Ω
load)
Output impedance 2.2 k
Ω
USB jack mini-B
USB communication
Hi-Speed USB (USB 2.0 compliant)
[LCD screen]
LCD panel used
3.8 cm (1.5 type) TFT drive
Total number of dots
67 200 (280×240) dots
[Power, general]
Power AA nickel hydride batteries (2)
2.4 V
AA alkaline batteries (2)
3.0 V
AC-LS5 AC Adaptor
(not supplied), 4.2 V
Power consumption (during shooting with LCD
screen on)
1.3 W
Operating temperature range
0° to
+
40°C (32° to
+
104°F)
(When using alkaline batteries: 5° to
+
40°C (41° to
+
104°F))
Storage temperature range
−
20° to
+
60°C (
−
4° to
+
140°F)
Dimensions 101.2 Ч 53.7 Ч 35.6 mm
(4 Ч 2
1
/
8
Ч 1
7
/
16
inches)
(W/H/D, protruding portions not
included)
Mass Approx. 195 g (0.4 lb 6.9 oz) (two
batteries “Memory Stick,” wrist
strap, and so on included)
Microphone Electret condenser microphone
Speaker Dynamic speaker
Exif Print Compatible
PRINT Image Matching II
Compatible
PictBridge Compatible
x BC-CS2A/CS2B Ni-MH battery
charger (supplied with the DSC-
P43)
Power requirements
AC 100 to 240V 50/60Hz
3 W
Output voltage
AA : DC 1.4 V 400 mA × 2
AAA : DC 1.4 V 160 mA × 2
Operating temperature range
0° to
+
40°C (32° to
+
104°F)
Storage temperature range
−
20° to
+
60°C (
−
4° to
+
140°F)
Dimensions 71 Ч 30 Ч 91 mm
(2 7 /
8
Ч 1 3 /
16
Ч 3 5 /
8
inches) (W/H/
D)
Mass Approx. 90 g (3 oz)
x AC-LS5 AC Adaptor (not supplied)
Input rating AC 100 to 240 V, 50/60 Hz
11 W, 0.16 to 0.09 A
Output rating DC 4.2 V, 1.5 A
Operating temperature range
0° to
+
40°C (32° to
+
104°F)
Storage temperature range
−
20° to
+
60°C (
−
4° to
+
140°F)
Dimensions Approx. 48 Ч 29 Ч 81 mm (1
15
/
16
Ч
1 3 /
16
Ч 3 1 /
4
inches) (W/H/D,
protruding portions not included)
Mass Approx. 130 g (5 oz)
Accessories
• HR6 (size AA) Ni-MH batteries (2) (DSC-P43
only)
• R6 (size AA) alkaline batteries (2) (DSC-P41
only)
• Battery case (1) (DSC-P43 only)
• BC-CS2A/CS2B Ni-MH Battery charger (1)
(DSC-P43 only)
• Power cord (mains lead) (1) (DSC-P43 only)
• USB cable (1)
• A/V connecting cable (1) (DSC-P43 only)
• Wrist strap (1)
• “Memory Stick” (16MB) (1)
• CD-ROM (USB driver: SPVD-012) (1)
• Operating Instructions (1)
Design and specifications are subject to change
without notice.
