29
STR2 Hardware Manual 920-0059B
1/30/2014
60
80
100
120
140
160
oz-in
12 VDC 24 VDC 48 VDC Connection: series
Drive settings: 2.2A/phase, 20000 steps/rev
HT23‐598, STR2
0
20
40
0 10 20 30 40 50
rps
20
30
40
50
60
oz-in
12 VDC 24 VDC 48 VDC Connection: series
Drive settings: 2.2A/phase, 20000 steps/rev
HT23‐595, STR2
0
10
0 10 20 30 40 50
rps
