The actual temperature of the motor depends on how much heat is conducted, convected or
radiated out of it. Our measurements were made in a 40°C (104°F) environment with the motor
mounted to an aluminum plate sized to provide a surface area consistent with the motor power
dissipation. Your results may vary.
Motor
Connection
Current
Setting (A)
Max Duty Cycle at 40°C Ambient
12VDC
24VDC
48VDC
HT08-020
4 leads
0.42
100%
100%
NR
HT08-021
4 leads
0.42
100%
100%
NR
HT11-012
4 leads
1.20
100%
100%
NR
HT11-013
4 leads
1.20
100%
100%
NR
5014-042
4 leads
1.00
100%
see chart
NR
HT17-268
parallel
1.61
100%
100%
see chart
HT17-271
parallel
2.04
100%
100%
see chart
HT17-275
parallel
2.04
100%
100%
see chart
HT23-595
series
2.20
100%
100%
100%
HT23-598
series
2.20
100%
100%
100%
HT23-601
series
2.20
100%
100%
100%
NR: power supply voltage is not recommended for this motor
