Introduction
Thank you for selecting an Applied Motion Products motor control. We hope our dedication to
performance, quality and economy will make your motion control project successful.
If there's anything we can do to improve our products or help you use them better, please call or
fax. We'd like to hear from you. Our phone number is (800) 525-1609 or you can reach us by fax
at (831) 761-6544. You can also email [email protected].
A Note About Names
The BLUDC9 was originally called the BLU200. If you have a BLU200, please follow the instruc-
tions for the BLUDC9.
The BLUDC4 was originally called the BLU100. If you have a BLU100, please follow the instruc-
tions for the BLUDC4.
Features
• Digital servo motor driver in compact package
• Operates from 24 to 48 volt DC power supply
• Operates in torque, velocity or position mode
• Accepts analog signals, digital signals and RS-232/485 serial commands
• BLuDC4 provides motor current up to 13.5 amps peak, 4.5 amps continuous
• BLuDC9 provides motor current up to 18 amps peak, 9 amps continuous
• Seven optically isolated digital inputs (15 inputs on -SE, -QE)
• Three optically isolated digital outputs (7 outputs on -SE, -QE)
• ±10 volt analog input for speed and torque control
