3.5 Audio Menu
The Audio menu can be used to set up the audio parameters.
Sub-Menu Value Description
Input DVI/HDMI Audio input is set to DVI/HDMI
by default. It is the only input
interface available.
Delay X frames Audio delay setting from -1 to
+2 frames.
Level -18, -12, -6, 0, +6, +12,
+18 dB Audio Output level setting.
Swap Channels 3
and 4 Off
On
When selected input channel 3
will be output on channel 4 and
input channel 4 will be output
on channel 3.
SDI Out Groups Auto
1
1+2
1+2+3
1+2+3+4
Off Set the embedded SDI active
audio groups.
Auto: All audio inputs will be
present on the SDI output.
Each group has 4 audio
channels, when 1+2+3+4 is
selected, all 16 audio channels
will be present.
Off: No embedded audio on SDI
output.
3.5.1 Supported Audio Sample Rates
• HDMI Input: 48 kHz
• SDI Output: 48 kHz
Note: The H2S-30 does not support audio sample rate conversions. If using the Embedded SDI
Audio output, you must use 48 kHz audio on the HDMI input. Using unsupported audio sample
rates will result in degraded audio output.
