4.2 Remote Controller Functions
Remote Control Function
Input source selection Select: DVI-D/HDMI, or Pattern.
Note: SDI and DVI-A buttons are unused
“IR lock” button Unused
“Reset” button Unused
“Menu” button Invoke the Menu System
“Exit” button Back one menu level
SDI Output format area Force the SDI output to:
480i
576i
720p
1080i
1080p
InRes (SDI Resolution Match Input)
InFps (SDI Frequency Match Input)
More formats are available through the menu system
“Up Arrow” button Unused
“Down Arrow” button Unused
“Left Arrow” button Navigate OSD left
“Right Arrow” button Navigate OSD right
“Select” button Ok/Select
Scaling Cycles through the image settings
De-Int Filter Cycles through the available De-int Filter settings
Status OSD Cycles through the OSD status options
Save Saves the current settings to flash
