2.1.3 S2H-30 Rear Panel
The S2H-30 rear panel is illustrated below:
Figure 3: S2H-30 Rear Panel View
The rear panel has the following connectors:
Connector Description
USB USB connector
HDMI out HDMI output connector
SDI-A in SDI input connector – Link A
SDI-B in SDI input connector – Link B
AES out AES output connector
Power Power supply connector
S2H.OM.001540.DRM Page 9 of 39 Version 1.4
