1
Fig. 7-a
Fig. 7-b
Fig. 7-c
Fig. 7-d
*** NOTE ***
before beginning this process, retrieve the com-
puter control code from the passenger side door
panel. (See Fig. 7-a.) Follow the instructions on the
Chip Voucher to receive a pre-programmed com-
puter chip from PAXTON Automotive.
A. Remove the passenger side door sill plate, fol-
lowed by the passenger side kick panel . This
will reveal the engine control computer and its
harnesses . The harnesses are secured using
clips, which are attached to a small metal
bracket . Pull the harnesses off the bracket,
then remove the two 7/32" bolts that secure
the bracket itself . Remove the bracket . (See
Fig. 7-b .)
B. Pull the harnesses down and out of the way,
creating unobstructed access to the computer .
Remove the 7/32" screw that secures the
retention strap (arrow, See Fig. 7-c) and pull
the computer out of the foot well . (See
Fig. 7-d .)
Section 7
ENGINE CONTROl COMPuTER REMOVAl & MODIFICATIONS
7. ENGINE CONTROL COMPUTER
REMOVAL & MODIFICATIONS
