8.14 Electronic Gearing, Master-slave operation
In the case of the “electronic gearing” functionality (see setup software and description of
GEARMODE parameter), the servo amplifier is controlled by a secondary feedback
device as a slave.
It is possible to set up master/slave systems, use an external encoder as a setpoint
encoder or connect the amplifier to a stepper motor control.
The amplifier is parameterized using the setup software (electronic gearing).
Primary Feedback: adjust on screen page "Feedback" (FBTYPE)
Secondary Feedback: adjust on screen pages "Position" and "Gearing" (EXTPOS,
GEARMODE)
Master-/Slave adjustment
Master: adjust encoder emulation on screen page "ROD/SSI/Encoder" (ENCMODE)
Slave: adjust on screen pages "Position" and "Gearing" (EXTPOS, GEARMODE)
The following types of external encoder can be used:
secondary Feedback type Connector
Wiring
diagram
GEARMODE
Incremental Encoder 5V X4 ð p.57 3, 5*, 13*, 15*
Incremental Encoder 24V X3
ð p.57
0, 2*, 10*, 12*
Sine/Cosine Encoder X2
ð p.58
6, 8*, 9*, 16*
SSI Encoder X4
ð p.59
7*, 17*
Pulse and Direction 5V X4
ð p.60
4, 14*
Pulse and Direction 24V X3 ð p.60 1, 11*
* adjustable via terminal screen of the setup software
The following table shows the allowed feedback combinations:
Secondary Feedback for Position control/Following
Primary
Feedback Sine Encoder
(X2) Increm. Encoder
5V/24V (X4/X3) Pulse&Direct.
5V/24V (X4/X3) SSI Encoder
(X4)
Resolver (X5)
FBTYPE= 0
EXTPOS= 1,2,3
GEARMODE=
6,8,9,16
FPGA= 0
ENCMODE= 0 EXTPOS= 1,2,3
GEARMODE=
0,2,3,5,10,12,13,15
FPGA= 0
ENCMODE= 0 EXTPOS= 1,2,3
GEARMODE=
1,4,11,14
FPGA= 0
ENCMODE= 0 EXTPOS= 1,2,3
GEARMODE=
7,17
FPGA= 1
ENCMODE= 2
Sine Encoder
(X2)
FBTYPE=
2,4,6,7,20
-
EXTPOS= 1,2,3
GEARMODE=
0,2,3,5,10,12,13,15
FPGA= 1
ENCMODE= 0 EXTPOS= 1,2,3
GEARMODE=
1,4,11,14
FPGA= 1
ENCMODE= 0 EXTPOS= 1,2,3
GEARMODE=
7,17
FPGA= 1
ENCMODE= 2
Encoder & Hall
(X2)
FBTYPE= 11,12
-
EXTPOS= 1,2,3
GEARMODE=
0,2,3,5,10,12,13,15
FPGA= 1
ENCMODE= 0 EXTPOS= 1,2,3
GEARMODE=
1,4,11,14
FPGA= 1
ENCMODE= 0
-
RS422 Encoder
(X4)
FBTYPE= 8,9
- - - -
Sensorless
FBTYPE= 10
-
EXTPOS= 1,2,3
GEARMODE=
0,2,3,5,10,12,13,15
FPGA= 0
ENCMODE= 0 EXTPOS= 1,2,3
GEARMODE=
1,4,11,14
FPGA= 0
ENCMODE= 0 EXTPOS= 1,2,3
GEARMODE=
7,17
FPGA= 1
ENCMODE= 2
