Page 21 Operational instructions for digital multibus instruments 9.17.023
4.20 C
APACITY UNIT INDEX
unsigned char 0…4 RW  Y 23 1/15
This parameter gives access to the limited unit table which is available for MBC-II and MBC3 type of
instruments.
Capacity unit index is a pointer to select an actual readout unit (see list below). For FLOW-BUS instruments all capacity
units are available for direct reading. Other field busses (eg. DeviceNet) are limited in options for direct reading
facilities.
capacity unit index (limited unit table)
0 1 2 3 4 5 6 7 8 9
Sensor
Type
0 bar mbar psi kPa cmH2O cmHg atm kgf/cm2
1 l/min ml/h ml/min l/h mm3/s cm3/min
2 kg/h kg/min kg/s g/h g/min g/s mg/h mg/min mg/s
3 ln/min mln/h mln/min ln/h m3n/h mls/min mls/h ls/min ls/h m3s/h
4 usrtype usrtype usrtype
name description
sensor type Indicator for type of sensor in instrument in relation with a list of units for direct reading
capacity unit index Points to the capacity unit for direct reading in list of available units
Example:
If you want to readout your instrument in ln/min, then make sure parameter “sensor type” is set to value 3 and
parameter “capacity unit index” is set to value 0. By means of parameter “capacity unit” the unit string can be read-
back as a 7 character string.
