Page 22 Operational instructions for digital multibus instruments 9.17.023
4.21 C
APACITY UNIT
unsigned char[7] see table RW  Y/N 129 1/31
This parameter gives access to the extended unit table which is available for MBC3 type of instruments
only.
For MBC-II type of instruments this parameter can only be read.
Only if sensor type = 4 (other sensor type) this parameter can be written
For MBC3 type of instruments this parameter can be read and written.
The easiest way to change a unit in the MBC3 type of instrument is to fill in the unit needed from the
table below in capacity unit.
The “Capacity unit” displays the unit name set by “Capacity unit index”. A valid “Capacity unit”(for example ln/min) can
also be entered here which changes the “Capacity unit index”. In MBC3 type of instruments the parameter is not
secured.
Extended unit table
Pressure
A
mbar(a) bar(a) gf/cm2a kgf/cma psi(a) torr(a) Pa(a) hPa(a) kPa(a) MPa(a)
atm(a) mmH2O(a) cmH2Oa mH2O(a) "H2O(a) ftH2Oa mmHg(a) cmHg(a) "Hg(a)
Pressure
G
mbar(g) bar(g) gf/cm2g kgf/cmg psi(g) torr(g) Pa(g) hPa(g) kPa(g) MPa(g)
atm(g) mmH2Og cmH2Og mH2O(g) "H2O(g) ftH2Og mmHg(g) cmHg(g) "Hg(g)
Pressure
D
mbar(d) bar(d) gf/cm2d kgf/cmd psi(d) torr(d) Pa(d) hPa(d) kPa(d) MPa(d)
atm(d) mmH2Od cmH2Od mH2O(d) "H2O(d) ftH2Od mmHg(d) cmHg(d) "Hg(d)
Mass Flow
ug/h ug/min ug/s mg/h mg/min mg/s g/h g/min g/s kg/h
kg/min kg/s
(Custom)
Volume
Flow
ul/h ul/min ul/s ml/h ml/min ml/s l/h l/min l/s cc/h
cc/min cc/s mm3/h mm3/m mm3/s cm3/h cm3/min cm3/s m3/h m3/min
m3/s cfh cfm cfs
Normal
Volume
Flow
uln/h uln/min uln/s mln/h mln/min mln/s ln/h ln/min ln/s ccn/h
ccn/min ccn/s mm3n/h mm3n/m mm3n/s cm3n/h cm3n/m cm3n/s m3n/h m3n/min
m3n/s scfh scfm scfs sccm slm
Standard
Volume
Flow
uls/h uls/min uls/s mls/h mls/min mls/s ls/h ls/min ls/s ccs/h
ccs/min ccs/s mm3s/h mm3s/m mm3s/s cm3s/h cm3s/m cm3s/s m3s/h m3s/min
m3s/s
Due to compatibility the maximum string length is limited to 7 characters. Therefore unit names may
be truncated. For instance mm3n/m means mm3n/min.
